• Easy arc adjustment from 0° to 360° for 10-, 12-, 15-, and 18-VAN;
  0° to 330° for 4-, 6- and 8-VAN.
• The textured base and collar are easy to grip, even when wet.
• A physical left edge indicator makes it easier to feel the fixed left edge.
• No special tools required. A small twist of the center collar increases or decreases arc setting.
• Stainless steel adjustment screw to adjust flow and radius.
• "Captured" screw slot prevents screwdriver slippage during adjustment.
• Ideal for watering odd-shaped areas.
• Blue filter screen (.02" x .02") (shipped with nozzles) maintains precise radius adjustment and prevents clogging.
• 12, 15, and 18-VAN have matched precipitation rates with Rain Bird MPR nozzles.
• Quickly identify radius with Top Color-coded™ nozzles. Top Color-coding makes it easy to verify proper nozzle installation, even when system is not operating.
• Fits all Rain Bird sprinklers and shrub adapters.
• Three-year trade warranty

Performance

• Radius: *
  4-VAN: 3 to 4 feet (0,9 to 1,2 m)
  6-VAN: 4 to 6 feet (1,2 to 1,8 m)
  8-VAN: 6 to 8 feet (1,8 to 2,4 m)
  10-VAN: 8 to 10 feet (2,4 to 3,0 m)
  12-VAN: 10 to 12 feet (3,0 to 3,7 m)
  15-VAN: 12 to 15 feet (3,7 to 4,6 m)
  18-VAN: 14 to 18 feet (4,3 to 5,5 m)
• Pressure: 15 to 30 psi (1 to 2,1 bar)
• Optimum pressure: 30 psi (2,1 bar) **
